100m Cct 12v 24v Dmx Ws2812b Ws2813 Small 60d Programmable Smd 5050 Addressable Rgb Blue Color Led Light Strip

FOB Reference Price:Get Latest Price
US $2-4 / Meter | 100 Meter/Meters (Min. Order)
Supply Ability:
5000 Meter/Meters per Day
Port:
Shenzhen
Report Suspicious Activity
Overview
Quick Details
Light Source:
LED
Item Type:
Light Strips
LED Light Source:
SMD5050
Type:
Flex LED Strips
Input Voltage(V):
12
Lamp Power:
72
Lamp Luminous Flux(lm):
--
CRI (Ra>):
75
Color Temperature(CCT):
RGB
Working Temperature(℃):
-20 - 50
Working Lifetime(Hour):
50000
Lamp Body Material:
Aluminum
Certification:
CE, RoHS
Emitting Color:
RGB addressable
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
OEM
Model Number:
TW-FR5050IC-60-12
Material:
SMD5050+Flexible PCB board
Power:
72W,DC12V,Max 6A
View Angle:
120degrees
Size:
L5000*W10mm*H3.5mm
LED quantity:
60leds/meter,3-led cuttable
Backside:
300LSE genuine 3M adhesive tape
IP Rank:
IP20 / IP65 / IP66 / IP68
Packaging & Delivery
Packaging Details
1). 5m/roll, 1 roll packaging with 1 anti-static bag;
2), Neutral packaging, neutral labels,no logo on PCB, and just English description of the product;
3). Carton Size: 40*30*40cm ;
Delivery Time
5-7 days after order confirmed

100m Cct 12v 24v Dmx Ws2812b Ws2813 Small 60d Programmable Smd 5050 Addressable Rgb Color Led Light Strip

Product description

Product Datasheet :



   1). 30leds/m, DC5V / 12V, MAX 7.2W/m, 5m/roll ;

   2). 60leds/m , DC5V / 12V, MAX 14.4W/m, 5m/roll ;

   3). DC5V , each 1 LED per PIXEL, and cuttable, addressable ;

   4). DC12V , each 3 LED per PIXEL, and cuttable, addressable ;

   5). Non-waterproof IP20 ;

   6). Waterproof IP65 -- Silicon gel  /  Silicon tube ;

   7). Waterproof IP68 -- Silicon tube + Injected Silicon gel ;



Items No.

LED Chips

LED Brightness

Color

LEDs(pcs)

Power

Voltage

TW-FR5050 IC-30-5V / 12V

Epistar smd 5050

2500 MCDRGB with built-in IC WS2812B30leds/mMAX 7.2W/m

DC5V / 12V

TW-FR5050 IC-60-5V / 12VEpistar smd 50502500 MCDRGB with built-in IC WS2812B60leds/mMAX 14.4W/m

DC5V / 12V
